Since the ordinary TFT display screen is basically the FPC soft cable lead-out, it is connected to the customer's main board through soldering or socket, and some products also need to have peripheral component circuits to be used.
In order to facilitate the use of customers, Xin Hongtai HOTLCD has designed a TFT module with a fixed adapter plate structure. It is a TFT module that is transferred from the ordinary TFT display to the customer's motherboard by adding PCB. The advantage is that the structure is convenient and convenient. Soldering peripheral components and interface options can be connected to the customer's motherboard.
At present, there are 1.44 inch, 1.8 inch, 2.0 inch, 2.4 inch, 2.8 inch, 3.2 inch, 3.5 inch and other sizes for customers to choose, generally used in industrial equipment.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Effective size mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.44寸TFT/128*128 Resolution/SPI serial /LCM-TFT014T1QQS4LN08D-V01 | TFT LCD | 128x128 |
|
30.0x46.5x3.4 | 1.44 | 1.44 | 25.5x26.5 | 12H | 400cd/m2 | 8PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 3.0V | ST7735S | |
| 3.5 inch TFT display module | | MCU8/16 bit interface built-in SSD1963 controller | HTM035A01 | TFT Module | 320x240 |
|
93.0x70.0x8.0 | 3.5 | 3.5 | 70.08x48.16 | 6H | 300cd/m2 | 15DIP/24FFC | MCU | 8/16BIT | -30~80℃ | 3.3V | SSD1963 | |
| 7 inch TFT display module | built-in SSD1963 MCU8/16 bit interface| controller built-in XPT2046 resistive touchscreen drives | LCM - TFT070T1 | TFT Module | 800x480 |
|
181.5x104.3x10.6 | 7.0 | 7.0 | 153.84x85.632 | 6H | 800cd/m2 | 40pin | MCU | With RTP | -20~70℃ | 5.0v | SSD1963 | |
| 5 inch hd TFT display module | built-in SSD1963 MCU8/16 bit interface| controller built-in XPT2046 resistive touchscreen drives | LCM - TFT050T1 | TFT MODULE | 800x480 |
|
143.5x81.0x8.12 | 5.0 | 5.0 | 108.0x64.8 | FULL | 300cd/m2 | 40DIP | MCU | with RTP | -20~70℃ | 5.0V | SSD1963 | |
| 4.3 inch TFT display module | built-in SSD1963 MCU8/16 bit interface controller |built-in XPT2046 resistive touchscreen drives | LCM - TFT043T1 | TFT MODULE | 800x480 |
|
121.0x70.0x7.76 | 4.3 | 4.3 | 95.04x53.85 | Full view | 300cd/m2 | 40pin | MCU | with RTP | -20~70℃ | 5.0V | SSD1963 | |
| 3.5''TFT LCM/4-Line SPI/LCM-TFT035C1HVS4LN8D-V01 | TFT LCM | 320x480 |
|
57.26x96.5x11.3 | 3.5 | 3.5 | 48.96x73.44 | 12H | 240cd/m2 | 8PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3v | ST7796S | |
| 4.3 inch TFT LCM/480*800/Full View/LCM-TFT043T1WVP16N34D-V01 | TFT Module | 480x800 |
|
60.86x104.50x2.50 | 4.3 | 4.3 | 56.16x93.60 | Full View | 600cd/m2 | MCU | Anti-static ESD 8KV | -20~70℃ | 3.3v | NT35510 | ||
| 7.0"8080 MPU interface(8/16 Bit Bus)/TFT LCM/800*480分辨率 /7"HTM070A01 | TFT LCM | 800x480 |
|
185.52x112.12x12. | 7.0 | 7.0 | 156.4x89.0 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 3.3v | SSD1963 | |||
| 2.8‘’TFT LCM/4Line -SPI/HTM028SPI-3 | TFT Module | 240x320 |
|
83.13x50.0x3.3 | 2.8 | 2.8 | 43.2x57.6 | 6H | 500cd/m2 | 14PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3v | ILI9341 | |
| 2.4寸TFT LCM/4line-SPI/HTM024SPI-3 | TFT Module | 240x320 |
|
72.26x43.0x3.6 | 2.4 | 2.4 | 36.72x48.96 | Full View | 850cd/m2 | 8PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 3.3v | ST7789V |
