The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.2"white background graphic display/128x64 graphic LCD module/FSTN gray image/KS0108/ks0107 or compatible HTM12864B-31W-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x14.0 | 72.0x39.0 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2"yellow-green graphic display/128x64 graphic LCD module/STN positive yellow-green backlight/KS0108 HTM12864B-01Y-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x14.0 | 72.0x39.0 | 66.52x33.24 | 0.52x0.52 | 6H | YG | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2"128X64 monochrome graphic LCD module|with yellow-green backlight|FSTN+ | Arduino HTM12864A-35S-A5P | Graphic LCD Module | 128x64 |
|
113.0x65.0x12.7 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | R/G/B | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2"128X64 monochrome graphic LCD module | with yellow-green backlight | STN gray positive display HTM12864A-11Y-A5P | Graphic LCD Module | 128x64 |
|
113.0x65.0x12.7 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | YG | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2" 128X64 Graphic LCD Module | White Backlight | STN(+) | Arduino | KS0107+KS0108 or compatible HTM12864A-11W-A5P | Graphic LCD Module | 128x64 |
|
113.0x65.0x12.7 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2"128X64 monochrome graphic LCD module|with white backlight | DFSTN(-) | MCU |Arduino HTM12864A-41W-A5P | Graphic LCD Module | 128x64 |
|
0.52x0.52 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2"128X64 Graphic LCD Module | White Backlight | STN(-) | Arduino |Transmissive Polarizer HTM12864A-25W-A5P | Graphic LCD Module | 128x64 |
|
113.0x65.0x12.7 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 3.2"128X64 monochrome graphic LCD module|with yellow-green backlight|STN(+) | 5.0v | Arduino HTM12864A-01Y-A5P | Graphic LCD Module | 128x64 |
|
113.0x65.0x12.7 | 72.0x39.5 | 66.52x33.24 | 0.52x0.52 | 6H | YG | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | K0108 | |
| 2.5"122X32 Graphic LCD|FSTN+display with Red green blue side backlight |Arduino HTM12232Z-35S-A5P | Graphic LCD Module | 122x32 |
|
84.0x44.0x13.9 | 60.0x18.0 | 48.76x14.36 | 0.41x0.36 | 6H | R/G/B | 24PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | |
| 2.5"122X32 Graphic LCD | STN positive display with yellow-green side backlight | Arduino HTM12232Z-11Y-A5P | Graphic LCD Module | 122x32 |
|
84.0x44.0x13.9 | 60.0x18.0 | 48.76x14.36 | 0.41x0.36 | 6H | white | 24PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 |
